TS120VA Mains Toroidal Transformer 120VA

Single-phase, mains toroidal transformer with a power of 120 VA

Rated power: 120VA
PRI voltage range: 1 – 500 V
Frequency: 50 – 60 Hz
SEC voltage range: 1 -1000 V (any taps)
Insulation / thermal class: II / B (130⁰C)
Max. ambient temperature: 40⁰C
Protection rating: IP-00
Insulation test: 4k VAC (RMS)

Outer diameter (D): 90 mm
Inner diameter (d): 34 mm
Height (h): 40 mm
Weight: 1.2 kg
